SCENE · G+3 RESIDENTIAL

LAT 19.0760° N · LON 72.8777° E

COLUMNS12

BEAMS28

SLABS4

FOOTPRINT142 m²

RENDERWIRE · LIVE

STRUCTURAL CAD · WEB & ANDROID

PocketPillar

From floor plan to bar bending schedule.

Draw your plan — PocketPillar places the columns and beams, checks them against IS 456 and IS 1893, and hands you the steel, concrete, cost and BBS. Free, in your browser. No install, no licence, no Excel sheet.

rocket_launchStart designing free androidDownload for Android

Don't want to draw anything? Open the sample G+1 building — finished columns, beams, BBS and estimate.

verified IS 456 · IS 1893 checkspublic Runs in any phone browserpayments Free to use

SCROLL

FEATURES · 01 → 05

Five tools.
One building, end‑to‑end.

From a blank plot to a stamped PDF report — every step happens on your phone.

01DRAFT

Draw Plans

Snap walls to a real-world grid in metric or imperial. Place columns, beams, slabs and footings with a tap.

02VISUALIZE

3D View

Lift any plan into a true 3D model. Pinch, pan and orbit the whole building before a single brick is laid.

03CORE

MATERIALQTYCOST

Concrete M2548.6 m³₹3,40,200

Steel Fe5004,920 kg₹3,69,000

Brick · 1st cl.22,400₹1,68,000

Cement OPC53312 bags₹1,24,800

TOTAL₹10,02,000

Smart Estimation

Bill of Quantities and cost rollup recalculated live as you draw — backed by current rate cards.

04SAFETY

Structural Validation

Spans, slenderness and load paths checked against IS 456 logic. Warnings appear right on the structure.

05EXPORT

SHEET 03 / 12A2 · 1:50

Export PDF

Sheet sets, BOQ tables and footing schedules — printable PDFs ready to share with the site team.

WORKFLOW · 3 STEPS

Plot to PDF
in three taps.

Sketch your plot

Trace the outline. Drop columns. The grid snaps everything to mm precision.

Validate the structure

Beams and columns are generated and checked against IS 456 logic. Issues surface in red.

Export in seconds

A printable sheet set, BOQ table and footing schedule — share straight to WhatsApp or email.

READY TO BUILD

Build smarter,
not harder.

Built in India for the site engineer who needs a column layout, a steel quantity and a BBS today — not a ₹1.5 lakh licence and a training course.

Get it on Google Play descriptionView Sample Report

infoEstimation tool only — designs and reports are not construction documents, and we accept no liability for their use. Always consult a certified Structural Engineer before construction. Full disclaimer
